The LCM3561 low profile compression load cell is rated to 10 tonnes. It has been designed for a wide range of force measurement and weighing applications where space is limited, including restricted height weighing applications, general force measurements and press calibration. Constructed from stainless steel the LCM3561 load cell also offers a high level of corrosion resistance for use in harsh environments.
LCM Systems can provide the LCM3561 on its own or combined with any of our instrumentation range to offer a more complete package. Please consult our sales team for any advice required on suitable instrumentation solutions.
On sale at £210 (normal selling price £496)
- Environmentally sealed to IP67
- Low height/profile
- Rated at 10 tonnes
- Reduced to £210
- Stainless steel construction
There are no options for this product.
- Process measurement & control
- Automotive testing
- Low profile weighing
- Press calibration
- General force measurement
