The latest news stories relating to our range of load cell and instrumentation products can be viewed below. This section will be updated regularly with application stories, articles, product updates and other interesting information relating to LCM Systems.
16,800kN Dual Bridge/Bi-Directional Load Pins
27th Jan 2023
Manufactured for one of our regular customers in The Netherlands were these four 16,800kN rated load pins. With a diameter of 340mm and 900mm long, each one weighs in at a hefty 620kgs.
These 150 tonne load pins have been manufactured for a leading supplier of mooring and berthing systems based in the EU. They are certified for use in Zone 1 & 2 hazardous areas, have integral amplifiers to provide a 4-20mA output and also come with 5m of steel armoured cable.
We have recently shipped this stainless steel toggle load link to one of our customers in Germany. It will be installed on the rollers of a conveyor belt in a port that loads fertiliser and sulphur onto vessels for onward transportation.
These tiny beam load cells have been manufactured for a UK customer that specialises in the investigation and removal of hazardous materials. The load cells will be installed on a U bracked that is fixed to a pneumatic motor to measure the reaction force
