Applications Tensile Test Machines
Tensile Test Machines
Tensile test machines measure the uniaxial force applied to a sample in tension. This is required to determine its strength, and therefore identify whether a component, part or product is suitable for its intended use. Testing consists of monitoring how the test sample reacts when a static or dynamic force is applied to it and is one of the most fundamental and common types of mechanical testing.
By measuring the material while it is being pulled, it is possible to obtain a complete profile of its tensile properties. When plotted on a graph, this data results in a stress/strain curve which shows how the material reacted to the forces being applied. The point of break or failure is typically the main purpose of the testing, but other important properties that can be measured include elasticity, yield strength and the effect the exposure to strain has on the sample.
LCM Systems has supplied many load cells for use in tensile test machines and can supply either a load cell from our standard range or can design a load cell to suit an individual tensile test machine. In addition to the load cell, we can also provide instrumentation and displays to provide a complete load measurement solution.
Below is a selection of some of our most popular standard load cell and sensor based products used for Tensile Test Machines applications
STA-1
- From 50kgs to 300kg
- Aluminium alloy construction
- Environmentally sealed to IP66
STA-2
- Ratings from 250kgs to 20 tonnes
- Fully welded stainless steel
- Environmentally sealed to IP68
STA-3
- From 50kgs to 1000kgs
- Alloy steel nickel plated construction
- Environmentally sealed to IP67
STA-4
- 50kgs to 5000kgs
- Alloy steel nickel plated construction
- Environmentally sealed to IP67
STA-7
- Ratings from 1kg to 50kgs
- High accuracy
- Aluminium alloy construction
TCA
- Ratings from 1 tonne to 100 tonnes
- Stainless steel construction
- Environmentally sealed to IP66
Below is a selection of our most popular standard instrumentation products used for Tensile Test Machines applications
DSC
- Strain gauge to digital data converter
- RS485 and RS232 versions available
- High speed (up to 500 readings/sec)
DSCUSB
- USB conditioning module
- Quick and easy connectivity via USB
- Strain gauge bridge input
DSJ1
- DSC docking station
- Single channel
- Digital outputs including RS232/RS485
PMD-STRAIN
- Load cell input
- Wide selection of outputs
- 14.2mm high red LED display
T24-ACMi
- Compact wireless sensor transmitter
- Battery powered for up to 2 months
- IP67 sealed enclosure
T24-HS-LS
- Simple wireless handheld indicator
- Connects to a single acquisition unit
- Gross/Net weight facility
TR150
- Battery powered
- Handheld and portable
- Load cell input
What Tensile Test Machines Applications have LCM Systems already satisfied?
Please review some of the recent news items relating to Tensile Test Machines load cells, load pins and associated instrumentation that we have supplied to our customer base. These will help demonstrate the experience we have in finding solutions for our customers, in a addition to the standard product offering available for this application.
10th Mar 2023
500N DCE Tension & Compression Load Cell
This tiny DCE tension and compression load cell has been purchased by a customer in France via our e-commerce website. Available ex-stock, our DCE load cells come in load ratings from 100N to 50kN.
1st Apr 2022
1500te Tension & Compression Load Cell
Recently shipped to a research institute in Germany that specialises in subsurface energy systems was this rather hefty 1500 tonne rated tension and compression load cell.
23rd Oct 2020
2000te Tension & Compression Load Cells
Awaiting collection are these two 2000 tonne stainless steel tension and compression load cells that have been ordered by a customer in China.
13th Dec 2019
Manufactured for a US customer and despatched this week were two of our 400 tonne telemetry load shackles.
28th Jun 2019
STA-4 Tension & Compression Load Cells
Supplied to one of our regular UK customers were these 5000kg rated STA-4 tension and compression load cells.
12th Apr 2019
200te Tension & Compression Load Cell
For a UK customer we have designed and manufactured a 200 tonne load cell suitable for use in both tension and compression.
22nd Mar 2019
50kN Tension & Compression Load Cells
Ready to go to a customer in Australia for a component testing application are these 50kN tension and compression load cells.
15th Jun 2018
200te Low Profile Compression Load Cell
Off to China this week is a 200te low profile compression load cell from our standard PTC-1 range.
5th Jan 2018
5000kg Stainless Steel S Type Load Cells
Being despatched today to one of our regular UK customers are these 5,000kg tension and compression S Type load cells.
22nd Sep 2017
100te Tension & Compression for Calibration Test Rig
Despatched earlier this week and on its way to one of our regular customers is a 100te TCA tension and compression load cell.
31st Aug 2017
5 x 1kN Tension Load Cells for Test Machine Application
In addition to the larger load cells we supply, we also manufacture much smaller load cells, like these DCE tension and compression load cells that will be despatched tomorrow to one of our UK customers.
24th Mar 2017
High Accuracy Load Cells for Test Machine Application
Being used in texture analysis and powder characterisation equipment are 10 of our smaller load cells.
