- Ratings from 2 tonnes to 1000 tonnes
- Stainless steel construction
- Environmentally sealed to IP67
Crane load monitoring and control systems are installed on all types of cranes to provide continuous data to operators and asset owners that allows them to increase productivity and improve safety. Monitoring of lifted loads enables the operator to move the maximum amount of product safely, resulting in fewer lifts and faster completion of duties. Additionally, as overload instances are eliminated, safety is improved and damage to the cane avoided. Information on crane usage and loads lifted also provides information to asset owners on integrity, life expectancy and required scheduling of maintenance and repairs.
LCM Systems offer a comprehensive range of weighing and overload systems to suit most applications. Our crane load monitoring and control systems can be fitted either to new cranes as original equipment or retrofitted to existing cranes. The type of load cell used in a system will depend on many factors including crane design, amount of headroom available and the level of accuracy needed, and so could comprise of a load link, load shackle or load pin.
Each system requires a load cell to sense the load and an indicator to display the load and provide any control outputs that may be required. We can supply just the load sensing component or the complete system with a display. For customers who already have a display or PLC system that they would like to integrate the load cell into, we offer various signal outputs for simple connection.
Below is a selection of some of our most popular standard load cell and sensor based products used for Crane Load Monitoring & Control applications
Below is a selection of our most popular standard instrumentation products used for Crane Load Monitoring & Control applications
Below is a selection of some of our custom design product solutions used for Crane Load Monitoring & Control applications
What Crane Load Monitoring & Control Applications have LCM Systems already satisfied?
Please review some of the recent news items relating to Crane Load Monitoring & Control load cells, load pins and associated instrumentation that we have supplied to our customer base. These will help demonstrate the experience we have in finding solutions for our customers, in a addition to the standard product offering available for this application.
24th Feb 2023
Dual Bridge Load Pins for Offshore Davit Cranes
Ready for delivery to an industry leading designer and manufacturer of onshore an offshore cranes are these 65kN rated load pins.
17th Feb 2023
3000lbf ATEX/IECEx Dual Bridge Load Pins
These ATEX/IECEx certified dual bridge load pins were manufactured for a customer that supplies crane monitoring and overload systems.
16th Dec 2022
Hazardous Area Load Pins for Crane Load Monitoring
These IECEx load pins have been purchased by our US distributors, Interface, Inc for a customer that manufactures marine and offshore cranes and winches.
4th Nov 2022
350klbf (159 tonne) Annular Load Cell
These three stainless steel annular load cells have been designed to fit the main hoist of a crane to provide load measuring data.
2nd Sep 2022
We have recently designed and manufactured 16 stainless steel tension load cells for our US distributor, Interface Force Measurement Solutions. They will ultimately be going to a marine crane and winch manufacturer.
7th Feb 2022
1750 Tonne Load Pins for Heavy Lift Application
Designed and manufactured for one of our regular customers that specialises in crane rental and heavy lifting applications were these 1750 tonne rated load pins.
26th Nov 2021
Y Load Links for Ship Deck Crane
Designed and manufactured for a customer in the USA, these Y stainless steel load links will be used to provide load monitoring on a ship deck crane.
15th Oct 2021
These stainless steel load pins have been despatched to a producer and exporter of ferroalloys and manganese ore in Georgia. They will be installed in the overhead bridge cranes in their processing plant.
16th Jul 2021
We have just despatched these 250 tonne ATEX/IECEx load shackles to a UK customer that specialises in the design of safety and control solutions.
4th Dec 2020
STA-3 1000kg Tension Load Cell
We have recently supplied this STA-3 1000kg rated load cell to a UK customer in the space industry that specialises in satellite-based systems. They will be installing it on a ceiling crane in their manufacturing facility.
16th Oct 2020
100 Tonne High Temperature Load Measuring Pins
Recently despatched and on their way to Chile are these two 100 tonne rated load measuring pins that will be installed in a crane to provide load monitoring.
7th Sep 2020
These 80kN wireless load pins have been designed and manufactured for a customer in Belgium, who wanted to replace an existing load bearing pin in an open wedge socket with a load measuring pin to provide load monitoring.
14th Aug 2020
400te Duplex Dual Bridge Load Links
Due for delivery early next week to a customer in Belgium are these four duplex load links rated to 400 tonnes. Each load link pair has a separate strain gauge bridge to give dual redundancy for additional safety protection and provides a 4-20mA output.
17th Apr 2020
10,400kN Load Pin for Offshore Crane
LCM System have designed and manufactured a 10,400kN (1060 tonne) load pin that will be installed in an offshore A-Frame crane to provide load monitoring during lifting operations.
24th Oct 2019
Currently going through our calibration facility are ten RTG container weighing systems for a port in Africa.
30th Aug 2019
120,000 lbf Load Pin for Crane Overload Application
Manufactured for a customer in Canada was this 120 klbf (53.4 tonne) stainless steel load pin which will be installed in a crane for overload monitoring.
22nd Feb 2019
We have recently completed an order for 25 wireless load pins, each rated to 250 tonnes, that will be installed in a crane lifting tackle arrangement to provide load monitoring.
